Manifold Fittings

MrPEX® Manifold Options offer transitions, end caps and accessories for MrPEX® manifolds. Some of the 1 1/4″ manifolds and transitions feature a 1″ BSP metric straight thread using an o-ring seal. Do Not Use teflon tape or thread sealing compounds for these.

Loop End Cap

3610003
Part # Type Unit
3610003 EK 20 Bag of 2
3610004 EK 25 Bag of 2

Pressure Test Kit for 1 1/4″ Brass & Stainless Steel Manifolds

Part # Type Unit
3610005 1″ BSP Each

Pressure Test Kit for Composite Manifolds & all 1″ NPT Connections

3700183
Part # Type Unit
3700183 1″ NPT Each

Pressure Test Kit for 1 1/2″ Brass & Stainless Steel Manifolds

Part # Type Unit
3700184 1 1/2″ & 1 1/4″ NPT Each

Manifold Transition for 1 1/4″ Brass & Stainless Steel

Part # Type Unit
3620001 1″ BSP to 1″ & 1 1/4″ CU Bag of 2
3620002 1″ BSP to 3/4″ NPT Bag of 2
3620003 1″ BSP to 1″ NPT Bag of 2
3620004 1″ BSP to 1″ FIP Bag of 2
3620005 1″ BSP to 1″ BSP (Manifold Double Nipple) Bag of 2
3620006 1″ BSP to EK 25 Bag of 2
3620007 1″ BSP to EK 32 Bag of 2

Large Dimension PEX ‘Push-Fit’ Transition

Part # Type Unit
4467575 3/4″ PEX x 3/4″ NPT Each
4461010 1″ PEX x 1″ NPT Each
4461313 1 1/4″ PEX x 1 1/4″ NPT Each
4461515 1 1/2″ PEX x 1 1/2″ NPT Each
4462020 2″ PEX x 2″ NPT Each

Disconnect Tool for PEX ‘Push-Fit’ Transition

Part # Type Unit
4460001 3/4″ Each
4460002 1″ Each
4460003 1 1/4″ Each
4460004 1 1/2″ Each
4460005 2″ Each
